Working Principle

1. Design Creation
   Designs are created using CAD software and converted into machine-readable G-code through CAM software.

2. Control System Execution
   The CNC controller interprets the G-code and sends commands to motors.

3. Material Cutting
   The spindle rotates at high speed while the router moves along X, Y, and Z axes to cut or engrave the material accurately.

Key Components

• Frame & Structure: Heavy-duty steel or aluminum body for stability

• Spindle Motor: High-speed motor for cutting (air or water-cooled)

• Linear Guide Rails & Ball Screws/Rack: Ensure smooth and precise movement

• Drive System: Stepper motors or servo motors

• Controller System: Controls machine movement and operations

• Worktable: Vacuum table or T-slot table to hold materials

• Tool Holder & Collets: Secure cutting tools

• Dust Collection System: Removes debris during operation

Types of CNC Routers

• 3-Axis CNC Router: Standard cutting and engraving

• 4-Axis CNC Router: Rotary axis for cylindrical objects

• 5-Axis CNC Router: Complex 3D machining and sculpting

• ATC CNC Router: Automatic Tool Change for industrial production

Materials Processed

• Wood, MDF, plywood

• Acrylic, PVC, foam board

• Aluminum, brass (light metals)

• Stone, marble, granite

• Composite panels and plastics

Applications

• Furniture Manufacturing: Doors, cabinets, panels

• Advertising Industry: Signboards, channel letters

• Woodworking & Carpentry: Carving, engraving, inlays

• Interior Decoration: Wall panels, partitions

• Mold & Pattern Making

• Musical Instruments & Handicrafts
