Working Principle

1. Laser Generation
   The CO₂ laser tube generates a high-energy infrared beam.

2. Beam Transmission
   The beam is reflected through high-precision mirrors and focused by a lens onto the material surface.

3. Material Processing
   The focused laser melts, burns, or vaporizes the material, enabling clean cutting or detailed engraving.

4. Motion Control
   The laser head moves along the X and Y axes on linear guide rails, following the design path defined by the control software.

Key Components

• CO₂ Laser Tube: Core laser source for cutting and engraving

• Flatbed Worktable: Honeycomb or blade table for stable material support

• Laser Head & Focusing Lens: Ensures sharp focus and precision

• Mirror System: Guides the laser beam accurately

• Motion System: Linear guide rails with stepper or servo motors

• Control System: Digital controller compatible with CAD/CAM software

• Cooling System: Water chiller for laser tube temperature control

• Exhaust & Air Assist System: Removes smoke and improves cut quality

Main Features

• Large flat working area for sheet materials

• High-precision cutting and engraving

• Smooth and stable machine structure

• Supports various design file formats (AI, DXF, PLT, BMP)

• Adjustable speed and power control

• Optional accessories such as rotary attachment or CCD camera

Applications

• Advertising Industry: Acrylic letters, signboards, nameplates

• Woodworking: MDF, plywood, wooden crafts

• Garment & Textile: Fabric cutting, applique work

• Leather Industry: Bags, wallets, belts, shoes

• Packaging Industry: Paper, cardboard, labels

• Gifts & Crafts: Personalized items and decorative products

Advantages

• Non-contact processing with no tool wear

• High accuracy and repeatability

• Smooth edges with minimal post-processing

• Suitable for both small-scale and industrial production

• Reduced material wastage and labor cost

Typical Technical Specifications

• Laser Power: 60W – 300W (CO₂)

• Working Area: 700×500 mm to 1600×3000 mm

• Cutting Accuracy: ±0.1 mm

• Maximum Cutting Speed: Up to 30,000 mm/min

• Supported Materials: Wood, acrylic, leather, fabric, rubber, paper
